080Z4028 - Danfoss AK-SM 880A Full Store System Manager Retro-fit TP78

Upgrade your store's refrigeration management with the 080Z4028 Danfoss AK-SM 880A Full Store System Manager Retro-fit TP78. This advanced system manager is designed for retrofitting existing setups, providing comprehensive control and monitoring capabilities.

The 080Z4028 Danfoss AK-SM 880A Full Store System Manager Retro-fit TP78 is tailored for retrofit applications, offering seamless integration and enhanced control over your store's refrigeration systems. This controller leverages the LON TP-78 communication protocol frequently used by Danfoss Controllers produced between 2001 and 2016.

Product Specifications:

• Type: AK-SM 880A - Retrofit
• Communication Type: CANBUS, ETHER, LON RS485, MODBUS, RS485
• Digital Outputs (DO): 2 pcs
• Supply Voltage: 100-240 V AC
• Frequency: 50/60 Hz
• Enclosure Rating IP: IP20
• Controller Type: System Manager
• Product Group: Supervisory Solutions
• Function: Data Collection, Monitor Unit
• Display on Front: Yes
• User-Friendly Interface: Features a front display and touchscreen for intuitive operation and monitoring.
• Product Language: Chinese, Czech, Danish, Dutch, English, French, German, Hungarian, Italian, Polish, Portuguese, Russian, Spanish
• Application Area: Full Store
• Approval: C UL US LISTED, C-TICK, CE, cURus

Licensed Features:

• Refrigeration Control
  • Suction Groups: 12
  • Compressors per Suction Group: 9
  • Circuits: 164
• HVAC Control
  • HVAC Units: 45
• Store Lighting Control
  • Lighting Zones: 30
• Energy Metering
  • Energy Meter Points: 80
• Refrigeration Gas Detection
  • Leak Detector Inputs: 50
• Miscellaneous Sensors (via AK I/O)
  • Relay Outputs: 70
  • Sensor Inputs: 70
  • On/Off Inputs: 80
  • Variable Outputs: 70
• Calculations and Conversion Factors
  • Calculation Points: 96
  • Conversion Factors: 10
• Alarm Management Configuration Options
  • Number of Alarms Stored Before Being Overwritten: 250
  • Number of Alarm Network Connections: 4
• History (logs)
  • Number of History Points: 600
  • Sample Rates: 5, 30 sec, 1, 2,10, 30 mins, 1 hour
• System Capacity
  • Max Reck/Pack Controllers: 12
  • Max Node Count: 120
  • Max Schedules: 100
  • Max Multiple Fonts Interconnected to Form ‘Host Network’: 10
• User Authorization
  • Auth Levels: 7
  • Users: 35

Transform your store's refrigeration management with the 080Z4028 Danfoss AK-SM 880A Full Store System Manager Retro-fit TP78. This advanced solution ensures optimal control, efficient energy management, and enhanced data visibility, making it the perfect choice for modern retail environments.
