810-3077 - Emerson Multiflex 1616LDO-16 Analog Ins
Original price
$2,422.03
Original price
$2,422.03
-
Original price
$2,422.03
Original price
$2,422.03
Current price
$2,156.30
$2,156.30
-
$2,156.30
Current price
$2,156.30
Call or chat for current availability.
The 810-3077 MultiFlex Combination I/O Board is a versatile solution for distributed control systems, offering a wide variety of input, output, and smart control capabilities based on a single universal hardware platform. Designed to save time and reduce space requirements by combining multiple inputs and outputs, this board is perfect for applications that demand high performance and flexibility.
Product Specifications:
- Relay Outputs: 16 low-voltage, non-fused relay outputs, rated for a maximum of 24V at 3.9A.
- Digital Outputs: 4 pulse-width modulating digital outputs (+8V at 10 mA) for precise control.
- Programmable Inputs: 16 configurable inputs that support both analog (0-5V) and digital signals, providing versatile monitoring capabilities.
- Power Requirement: Requires 24V, powered by a non-center tapped transformer delivering more than 20VA.
- Mounting Dimensions: Fits standard snap track for easy integration into existing systems.
Product Features:
- Universal Hardware Platform: Combines both analog/digital inputs and relay/digital/analog outputs on a single board, reducing space and simplifying system integration.
- Space-Saving Design: Reduces I/O board space requirements by up to 50%, making it an ideal choice for compact control systems.
- Dual Voltage Outputs: Provides both +5VDC and +12VDC output voltage points to power transducers or other devices that require additional power.
- Easy Mounting: Can be mounted using standoffs or snap track, offering flexible installation options.
Compatibility:
- Ideal for use with CPC control systems.
The 810-3077 MultiFlex Combination I/O Board is a highly flexible and efficient solution for complex control systems. Contact us for more information and availability.
